N,N'-二水楊醛縮-1,2-苯二胺(3946-91-6)核磁圖(1HNMR)
分子式:C20H16N2O2
分子量: 316.35
InChI:InChI=1S/C20H16N2O2/c23-19-11-5-1-7-15(19)13-21-17-9-3-4-10-18(17)22-14-16-8-2-6-12-20(16)24/h1-14,23-24H
InChIKey: HXFYGSOGECBSOY-UHFFFAOYSA-N
Smiles:C1(N=CC2=CC=CC=C2O)=CC=CC=C1N=CC1=CC=CC=C1O
-
Mass
MS-KW-0421
N,N'-disalicylidene-o-phenylenediamine
C20H16N2O2 (Mass of molecular ion: 316)
Source Temperature: 200 °C
Sample Temperature: 160 °C
Direct, 75 eV
17.0 1.7
18.0 8.8
27.0 1.5
28.0 2.6
39.0 6.0
50.0 3.0
51.0 13.6
52.0 4.3
53.0 1.4
63.0 3.4
64.0 2.7
65.0 8.5
66.0 2.0
75.0 2.0
76.0 3.4
77.0 26.2
78.0 10.9
79.0 1.8
83.5 2.4
89.0 1.7
90.0 2.1
91.0 5.3
92.0 5.7
93.0 1.4
94.0 2.4
97.0 1.4
102.0 7.6
103.0 1.7
104.0 3.9
105.0 3.3
106.0 1.4
107.0 9.1
108.0 1.3
111.0 3.4
115.0 4.1
116.0 1.3
118.0 1.6
119.0 7.0
120.0 15.3
120.5 1.0
121.0 2.9
122.0 1.4
127.0 1.6
128.0 2.0
129.0 4.1
130.0 1.0
134.0 2.1
134.5 2.5
135.0 1.5
139.0 3.3
140.0 3.3
141.0 2.9
143.0 1.4
149.0 1.7
151.0 2.7
152.0 3.8
153.0 1.6
154.0 1.2
156.0 1.2
157.0 1.4
158.0 11.7
158.5 2.1
166.0 3.3
167.0 9.2
168.0 7.4
169.0 2.7
177.0 1.1
178.0 1.8
179.0 1.7
180.0 13.8
181.0 12.8
182.0 9.8
183.0 1.7
192.0 1.2
193.0 1.9
194.0 5.7
195.0 6.0
196.0 63.4
197.0 20.2
198.0 2.5
205.0 1.1
206.0 1.4
209.0 1.3
210.0 100.0
211.0 17.2
212.0 2.6
221.0 8.5
222.0 5.2
223.0 42.2
224.0 7.2
269.0 1.6
285.0 1.3
287.0 1.0
297.0 1.1
299.0 25.8
300.0 6.1
301.0 1.0
314.0 1.7
315.0 15.3
316.0 92.9
317.0 20.7
318.0 2.7
370.0 1.4
