Mass

MS-IW-8357
diethyl 2,5-dioxahexanedioate
C8H14O6             (Mass of molecular ion:    206)

   Source Temperature: 220 °C
   Sample Temperature: 150 °C
   Reservoir, 75 eV

      15.0       5.1
      18.0       2.4
      19.0       3.3
      26.0       8.2
      27.0      23.5
      28.0      28.3
      29.0      84.9
      30.0       3.7
      31.0      72.6
      32.0       5.3
      33.0       1.2
      41.0       4.1
      42.0       2.5
      43.0      24.4
      44.0      88.3
      45.0     100.0
      46.0       5.2
      47.0       2.4
      57.0       2.1
      58.0       1.0
      59.0      14.1
      61.0       5.8
      63.0      69.0
      72.0       7.6
      73.0       2.1
      74.0       1.0
      75.0       1.0
      76.0      22.6
      77.0       3.1
      88.0       9.3
      89.0      64.7
      90.0       2.8
      91.0      75.1
      92.0       2.6
     104.0      10.7
     105.0       1.8
     116.0      12.9
     117.0      17.8
     118.0       2.6
     119.0       3.5

Parameter ppm Hz D(A) 4.359 D(B) 4.212 D(C) 1.314 J(B,C) 7.20

     Hz     ppm     Int.

   1307.69   4.359   1000
   1274.46   4.248    122
   1267.25   4.224    367
   1260.06   4.200    375
   1252.87   4.176    127
    401.37   1.338    379
    394.18   1.314    747
    387.00   1.290    367
