返回ChemicalBook首頁>CAS數(shù)據(jù)庫列表>2155-94-4更多圖譜> 二甲基烯丙基胺(2155-94-4)紅外圖譜(IR1)

2155-94-4

二甲基烯丙基胺(2155-94-4)紅外圖譜(IR1)

產(chǎn)品名稱:二甲基烯丙基胺

CAS:2155-94-4

分子式:C5H11N

分子量: 85.15

InChI:InChI=1S/C5H11N/c1-4-5-6(2)3/h4H,1,5H2,2-3H3

InChIKey: GBCKRQRXNXQQPW-UHFFFAOYSA-N

Smiles:C(N(C)C)C=C

  • 圖譜
    Mass

    MS-NW-3224
N,N-dimethylallylamine
C5H11N              (Mass of molecular ion:     85)


       Source Temperature: 280 °C
   Sample Temperature: 180 °C
   Reservoir, 75 eV


          15.0       8.0
      18.0       1.1
      26.0       1.0
      27.0       3.1
      28.0       2.8
      29.0       2.4
      30.0       7.4
      38.0       1.8
      39.0      10.5
      40.0       2.0
      41.0      23.5
      42.0      41.9
      43.0       7.7
      44.0      11.6
      55.0       1.0
      56.0       1.3
      57.0       1.4
      58.0     100.0
      59.0       4.1
      68.0       3.2
      69.0       1.3
      70.0      11.3
      78.0       2.6
      82.0       2.5
      83.0       1.6
      84.0      24.6
      85.0      40.5
      86.0       2.5

90 MHz in CDCl3

  • 圖譜

    1H NMR 89.56 MHz
    C5 H11 N 0.04 ml : 0.5 ml CDCl3
    N,N-dimethylallylamine
    ChemicalStructure
        Assign.     Shift(ppm)

      A             5.833
      B             5.14
      C             5.10
      D             2.910
      E             2.219

     J(A,B)=17.3HZ. J(A,C)=9.7HZ. J(A,D)=6.4HZ. J(B,D)=J(C,D)=1.1HZ.


         Hz     ppm     Int.


        512.13   5.719     42
    470.00   5.248     33
    468.88   5.236     56
    467.56   5.221     30
    463.56   5.176     50
    462.44   5.164     37
    453.56   5.065     51
    451.94   5.047     64
    450.81   5.034     30
    263.63   2.944     78
    262.50   2.931     50
    257.25   2.873     73
    256.06   2.860     45
    198.81   2.220   1000

in CDCl3

  • 圖譜

liquid film

  • 圖譜

×
