對氯苯乙酸(1878-66-6)紅外圖譜(IR2)

產(chǎn)品名稱:對氯苯乙酸

CAS:1878-66-6

分子式:C8H7ClO2

分子量: 170.59

InChI:InChI=1S/C8H7ClO2/c9-7-3-1-6(2-4-7)5-8(10)11/h1-4H,5H2,(H,10,11)

InChIKey: CDPKJZJVTHSESZ-UHFFFAOYSA-N

Smiles:C1(CC(O)=O)=CC=C(Cl)C=C1

Mass

MS-NW-4721
(p-chlorophenyl)acetic acid
C8H7ClO2            (Mass of molecular ion:    170)

   Source Temperature: 200 °C
   Sample Temperature: 180 °C
   Reservoir, 75 eV

      37.0       1.2
      38.0       1.9
      39.0       4.8
      43.0       1.2
      44.0       1.1
      45.0       2.1
      50.0       3.4
      51.0       3.3
      61.0       1.7
      62.0       4.0
      62.5       1.2
      63.0       9.7
      64.0       1.7
      65.0       1.8
      73.0       2.8
      74.0       1.2
      75.0       1.8
      77.0       2.7
      86.0       1.3
      87.0       1.3
      89.0      22.6
      90.0       5.8
      91.0      14.4
      92.0       1.2
      99.0       4.5
     101.0       1.4
     124.0       5.7
     125.0     100.0
     126.0       9.7
     127.0      32.6
     128.0       2.9
     152.0       8.5
     154.0       2.7
     170.0      35.1
     171.0       3.2
     172.0      11.4
     173.0       1.0

90 MHz in CDCl3

¹H NMR	89.56 MHz
C₈ H₇ Cl O₂	0.043 g : 0.5 ml CDCl₃
(p-chlorophenyl)acetic acid

    Assign.     Shift(ppm)

      A            11.29
      B             7.29
      C             7.20
      D             3.602

     Hz     ppm     Int.

   1011.29  11.292     97
    659.24   7.361    125
    658.22   7.350     97
    656.34   7.329     72
    653.00   7.292    116
    650.35   7.262   1000
    648.99   7.247    359
    648.22   7.238    387
    647.11   7.226    782
    644.37   7.195     95
    641.13   7.159     52
    639.16   7.137     74
    638.39   7.129     95
    322.66   3.603    979

in CDCl3
