返回ChemicalBook首頁>CAS數(shù)據(jù)庫列表>10489-75-5更多圖譜> 5,6-二氫-2,3-二甲酸酐(10489-75-5)質譜(MS)

10489-75-5

5,6-二氫-2,3-二甲酸酐(10489-75-5)質譜(MS)

分子式:C6H4O3S2

分子量: 188.22

InChI:InChI=1S/C6H4O3S2/c7-5-3-4(6(8)9-5)11-2-1-10-3/h1-2H2

InChIKey: MXSSHXZXAAXCOW-UHFFFAOYSA-N

Smiles:O1C(=O)C2SCCSC=2C1=O

  • 圖譜
    Mass

    MS-KW-0423
5,6-dihydro-1,4-dithiin-2,3-dicarboxylic anhydride
C6H4O3S2            (Mass of molecular ion:    188)


       Source Temperature: 170 °C
   Sample Temperature: 130 °C
   Direct, 75 eV


          26.0       1.1
      27.0       2.6
      28.0       2.0
      44.0       7.1
      45.0       7.3
      46.0       1.2
      55.0       3.8
      56.0       4.0
      57.0       1.6
      58.0       3.0
      59.0       5.3
      60.0      22.4
      62.0       1.0
      71.0       3.4
      72.0       2.0
      84.0       3.8
      88.0      43.0
      89.0       1.8
      90.0       4.0
     116.0      30.4
     117.0       1.6
     118.0       2.8
     144.0       9.7
     188.0     100.0
     189.0       8.3
     190.0       9.9

400 MHz in CDCl3

  • 圖譜

    1H NMR 399.65 MHz
    C6H4O3S2 0.038 g : 0.5 ml CDCl3
    5,6-dihydro-1,4-dithiin-2,3-dicarboxylic anhydride
    ChemicalStructure
        Assign.     Shift(ppm)

     A           3.394


         Hz     ppm     Int.


       1356.69   3.394   1000

in CDCl3

  • 圖譜

KBr disk

  • 圖譜

Nujol

  • 圖譜

×
